Datasheet
3 beams : F Band (3300 – 4200 MHz)
4×4 MIMO
Production: Ready
Request quote
Lens Technology Enabled™ Multi-Beam Base-Station Antenna perfect for six to nine sector LTE cell site deployments, utilizes a patented spherical lens design with 3 isolated CBRS-frequency (3300 – 4200MHz) cross- polarized beams. Each beam has 4 ports, or 4X4 MIMO.
Tilt is adjustable from 0° to 15° for each beam.
| Product Category | Antenna |
|---|---|
| Band Count | Single Band |
| Band Type | F Band |
| Product Family | MBA |
| Production Status | Ready |
| RET Available | Yes |
| Manual Tilt Adjust | Yes |
| H x W x D (cm) | 118.8 x 29.4 x 37 |
| H x W x D (inch) | 46.8 x 11.6 x 14.6 |
| Weight (kg) | 15 |
| Weight (lbs) | 33 |
| Application | Macros |
| RET Controller | M-RET |
| ILF | No |
| SBT | No |
| MIMO Capability F-Band | 4X4 |
| Product Milestone | ML7 |
| Gen-II | YES |
| MIMO Capability | 4X4 |
| Frequency | 3300-4200 |
| Beams | 3 |
Pattern Files (Asset)
Pattern Files (Paf-x)
Pattern Files (3D Vex)
Pattern Files (iBWave)
Pattern Files (iBWave Combined Version)
MS-MBA Series Antenna Unpacking Instructions
MS-MBA Series Antenna Unpacking Label
Crate Dimensions
| L x W x H (cm) | 143 x 49 x 66 |
| L x W x H (inches) | 57 x 20 x 26 |
